Description
User Manual: DS-2CE5AD3T-VPIT3ZF
Quick Start Guide: DS-2CE5AD3T-VPIT3ZF
| Camera | |
|---|---|
| Signal System: | PAL/NTSC |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s |
| Lens Mount: | φ14 |
| Adjustment Range: | Pan: 0° to 340°, Tilt: 0° to 75°, Rotation: 0° to 355° |
| Day& Night: | IR cut filter with auto switch |
| Video Frame Rate: | PAL: 1080p@25fps NTSC: 1080p@30fps |
| Synchronization: | Internal Synchronization |
| Menu | |
| BLC: | Support |
| General | |
| Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | 12 VDC±15% |
| Impact Protection: | IK10. |
| Weather Proof: | IP67 |
| IR Range: | Up to 40m |
| Dimension: | 84.5 mm × 92 mm × 255.1 mm (3.33″ × 3.62″ × 10″) |
| Weight: | Approx. 830 g (1.83 lb.) -A: Approx. 870 g (1.92 lb.) |
