Description
| System Parameters | |
|---|---|
| Operation System: | Embedded Linux Operation System |
| Processor: | High-Performance Embedded SOC Processor |
| Camera Parameters | |
| Image Sensor: | CMOS 2MP HD Colorful Camera |
| Light sensitivity: | Low Illumination |
| Lens: | f1.96 mm, F 2.2 |
| Field of view: | 180° (Horizontal), 96°(Vertical) |
| Audio Parameters | |
| Audio Input: | Built-in Omnidirectional Microphone |
| Audio Output: | Built-in Loudspeaker |
| Audio streaming: | Two-Way, Full Duplex |
| Audio Compression Standard: | G.711 U |
| Audio Compression Rate: | 64 Kbps |
| Audio Quality: | Noise Suppression and Echo Cancellation |
| Video Parameters | |
| Video streaming: | Dual Stream Main Stream: 1080P, Sub-Stream: VGA |
| Video Compression Standard: | H.264 |
| Anti-flicker frequency: | 50 Hz, 60 Hz |
| Wide dynamic range: | WDR |
| Network Parameters | |
| Network Protocol: | TCP/IP, RTSP |
| Interface number: | 1 Wireless Interface (Wireless Network Card), Supporting 2.4 GHz |
| Light Supplement | |
| Light Supplement Mode: | IR Supplement |
| Wavelength: | 940 nm |
| Event actions | |
| Event: | Motion Detection |
| Device Interfaces | |
| TF Card (micro SD card): | Max. 128 G |
| Button: | 1 Call Button, 1 Reset Button |
| General | |
| Power Supply: | 12 VDC |
| Power Consumption: | Max. 0.6 A |
| Power frequency: | 50 Hz to 60 Hz |
| Working Humidity: | 10% to 90% |
| Working Temperature: | -30° C to +50° C (-22° F to 122° F) |
| Dimensions(L × W × H): | 122.4 mm x 45.9 mm x 28.1 mm (4.82″ x 1.81″ x 1.11″) |
| IP Protection Level: | IP 54 |
