Description
| System Parameters | |
|---|---|
| Internal card reader: | Built-in Card Reader |
| Processor: | Embedded MCU Processor |
| Device Interfaces | |
| Module-connecting: | 2(1 Input, 1 Output) |
| General | |
| Card type: | Mifare Card |
| Power output: | 12VDC(Powered for the other module) |
| Power input: | 12VDC(Powered by the other module) |
| DIP switch: | 8 |
| Installation: | Flush Mounting, Surface Mounting |
| Power Consumption: | ≤2W |
| Working Humidity: | 10% to 95% |
| Working Temperature: | -40° C to +60° C (-40° F to 140° F) |
| IP Protection Level: | IP65 |
| Dimensions(L × W × H): | 98.5mm×100mm×33.7mm(3.87″×3.95″×1.33″) |
