Description
| Display Parameters | |
|---|---|
| Display Screen: | 7-Inch Colorful TFT LCD |
| Display Resolution: | 800 × 480 |
| Operation Method: | Physical Button |
| Audio Parameters | |
| Audio Input: | Built-in Omnidirectional Microphone |
| Audio Output: | Built-in Loudspeaker |
| Audio Quality: | Noise Suppression and Echo Cancellation |
| Device Interfaces | |
| Four-wire Interface: | 1 Four-Wire Interface (1-ch Video Input, 1-ch Audio Input/Output, 1-ch Power Supply, 1-ch Grounding) |
| General | |
| Power Supply: | 12 VDC |
| Power Consumption: | ≤5 W |
| Working Humidity: | 10% to 90% |
| Working Temperature: | -10° C to + 55° C (14° F to 131° F) |
| Dimensions(L × W × H): | 195.8 mm × 132.8 mm × 18.39 mm (7.7″ × 5.2″ ×0.7″) |
| Audio Parameters | |
| Audio Input: | Built-in Omnidirectional Microphone |
| Audio Output: | Built-in Loudspeaker |
| Audio Quality: | Noise Suppression and Echo Cancellation |
| Video Parameters | |
| Camera: | 1/4″ CMOS |
| Resolution: | 720 × 576 |
| Video frame rate: | PAL: 25 fps |
| Light Supplement | |
| Light Supplement Mode: | Photosensitive IR Supplement, IR Range: 2 Meters |
| Device Interfaces | |
| I/O Output: | 1 Relay Output |
| Four-wire Interface: | 1 Four-Wire Interface (1-ch Video Input, 1-ch Audio Input/Output, 1-ch Power Supply, 1-ch Grounding) |
| General | |
| Power Consumption: | Max. 3W |
| Material: | Aluminum Alloy |
| Working Humidity: | 10% to 90% |
| Working Temperature: | -30° C to +60° C (-22° F to 140° F) |
| Dimensions(L × W × H): | 128 mm × 42 mm × 24.8 mm (5.0″ × 1.7″ × 0.9″) |
