Description
General
- Core Color: 1 White- Blue /Blue 2 White-Orange /Orange,3 White- Green /Green 4 White- Brown /Brown,
- Packing: Wooden Tray & Carton
- Carton Dimension: Per request
- Packing Length: (305±1.5)m
- Rip-Cord: Yes
- Drain Wire: No
- Sheath Physical Properties: Before Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150,Aging Period(℃×hrs) 100℃×24h×10d,After Aging Tensile Strength(Mpa) ≥12.5, Elongation(%) ≥125,Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks,
- Electrical Characteristics (20℃): 1.0-100.0MHz Impedance(Ω) 100±15,1.0-100.0MHz Delay Skew (ns/100m) ≤45,DC ResistanceΩ/100m) max 9.5,DC Conductor Resistance Unbalance(%) max 5.0,
Conductor
- Material: Solid-Bare Copper,Content 99.95%,
- Nom.O.D.(Mm): 0.500±0.005
Insulation
- Material: HDPE
- Diameter: 0.88±0.04mm
Sheath
- Thickness: 0.50±0.05 mm
- External O.D: 5.0±0.4 mm
- Surface: Clean,Frap,Satiation
- Material: PVC(complies RoHS),CM
- Color: Grey ZLC1003
Surface Printing
- Letter Height: 3.0±0.3mm
- Color: Black
- Print Error & Space: ≤±0.5%，1m
