Datasheet: DS-2CE56D8T-AVPIT3ZF
User Manual: DS-2CE56D8T-AVPIT3ZF
| Model | ||
|---|---|---|
| Camera | ||
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1920(H)*1080(V) | |
| Min. Illumination: | Color: 0.005 Lux @ (F2.0, AGC ON), 0 Lux with IR | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens: | 2.8 mm to 12 mm motorized vari-focal lens | |
| Lens Mount: | φ14 | |
| Adjustment Range: | Pan: 0° to 340°, Tilt:0° to 75°, Rotate: 0° to 355° | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | 75dB | |
| Video Frame Rate: | 1080p@25fps/1080p@30fps | |
| HD Video Output: | 1 Analog HD output | |
| Synchronization: | Internal Synchronization | |
| Up the Coax: | Support | |
| Menu | ||
| AGC: | Support | |
| Language: | English/Chinese | |
| Function: | Brightness, Sharpness, Mirror, Smart IR | |
| General | ||
| Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
|
| Power Consumption: | Max. 7W | |
| IR Range: | Up to 40m | |
| Dimension: | Φ 145.2 mm × 124.1 mm (Φ 5.72″ × 4.89″ ) | |
| Weight: | Approx. 1600 g (3.53 lb.) | |
