Description
Camera
Image Sensor 2.0 megapixel progressive scan CMOS
Signal System NTSC
Video Frame Rate 1080p @ 30 fps
Resolution 1920 (H) × 1080 (V)
Minimum Illumination Color: 0.005 lux @ (ƒ/1.2, AGC on), 0 lux with IR
Shutter Speed 1/30 s to 1/50,000s
Lens 2.8 mm, 3.6 mm, and 6 mm fixed lens options
Horizontal Field of View 106° (2.8 mm), 82° (3.6 mm), 51° (6 mm)
Lens Mount M12
Day/Night IR cut filter
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Synchronization Internal synchronization
WDR (Wide Dynamic Range) >120 dB
Menu
AGC High/medium/low
D/N Mode Auto/color/BW (black and white)
Image Mode Standard/high-sat
BLC (Backlight Compensation) Yes
WDR Yes
3D DNR Level 1 to 9
Language English
Functions Brightness, sharpness, 3D DNR, mirror, smart IR
Interface
Video Output 1 HD analog output
Switch Button TVI/AHD/CVI/CVBS
General
Operating Conditions -40° to 140° F (-40° to 60° C), humidity: 90% or less (non-condensing)
Power Supply 12 VDC ±25%
Power Consumption Maximum 4.6 W
Ingress Protection IP67
Material Metal
IR Range Up to 100 ft (30 m)
Dimensions 3.52″ × 2.68″ (89.47 mm × 68.2 mm)
Weight Approximately 0.53 lbs (240 g)
