Description
| LED Module | |
|---|---|
| Module type: | SMD LED(one luminous led integrated by three led beads ) |
| Pixel pitch: | 2.54 |
| Resolution (W × H): | 60×45 |
| Dimensions (W × H): | 152.48mm×114.36mm |
| Optical | |
| Brightness (nits): | ≥800 |
| Color temperature: | 3000 to 10000 adjustable |
| Viewing angle: | Horizontal 170°, vertical 170° |
| Brightness uniformity: | ≥ 97% |
| Center distance deviation of LED: | < 3% |
| Color uniformity: | ≤ ± 0.003 Cx, Cy |
| Contrast: | ≥3000 : 1 |
| LED Unit | |
| Modules component (W × H): | 4×3 |
| Resolution (W × H): | 240×135 |
| Pixel density: | 154841 points /m² |
| Screen area: | 0.2093 m2 |
| Aspect ratio: | 16 : 9 |
| Electrical | |
| Max. consumption (W/m2): | 850 |
| Average consumption (W/m2): | 275 |
| Power supply: | 100 to 240 VAC ± 15% |
| Processing Performance | |
| Driving mode: | 1/27 scan constant current drive |
| Frame frequency: | 60 Hz |
| Refresh rate: | 3840 Hz |
| General | |
| Working hours: | >100,000 |
| Working temperature: | -10 to 40 o C (14 to 104 o F) |
| Storage temperature: | -20 to 60 o C (-4 to 140 o F) |
| Working humidity: | 10 to 80 % (non-condensing) |
| Storage humidity: | 10 to 85% (non-condensing) |
| Dimensions (W × H × D): | 609.92mm(W)×343.08mm(H)×75mm(D) |
| Weight: | 37.32kg/m² |
| Ingress protection: | IP5X |
| Material: | Aluminium |
