Description
| LCD Screen | |
|---|---|
| Diagonal screen size: | 70″ |
| Backlight: | LED Backlight |
| Max. resolution: | 2K(1920 × 1080) |
| Brightness: | 350 cd/m² |
| Contrast: | 3000: 1 |
| Response time: | 4 ms |
| Color: | 0.807 mm × 0.807 mm |
| Color: | 8 bit |
| Viewing Angle: | Horizantal 178°, vertical 178º |
| Hue: | 92% |
| Active Area: | 1549.44 × 871.56 mm |
| Touch | |
| Touch mode: | IR/Optical touch |
| Glass Thickness: | 4mm |
| Glass transmittance: | ≥ 92% |
| Touch point: | 10-point touch |
| Input method: | Finger or touch pen |
| Touch response time: | ≤ 8ms |
| Touch precision: | ±2mm |
| Min. touch object: | Non-transparent object with diameter ≥ 6mm |
| Anti-glare: | Yes |
| Video input: | 4, HDMI interface 2, VGA interface 1, YPbPr interface 1, AV-IN interface |
| Audio input: | 3, AUDIO-IN interface |
| Audio output: | EARPHONE SPDIF-OUT |
| Network: | 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| USB interface: | 3, USB (PC+ Android) on front panel 2, Android-USB on side panel 1, TOUCH-USB |
| RS-232 interface: | 1 |
| General | |
| Casing Material: | Aluminum alloy |
| Color of Casing: | Black |
| Wall-mounting Hole: | (VESA) 600 × 400 mm |
| Wall-mounting Screw: | 4 × M8 |
| Power Supply: | 100 to 240 VAC, 50/60Hz |
| Power Consumption: | ≤ 350 W |
| Standby Power Consumption: | ≤ 1.5 W |
| Working Temperature: | 0 to 40 º C (0 to 104 º F) |
| Working Humidity: | 20 to 80 % (non-condensing) |
| Dimensions (without base): | 1688 × 1055 × 96 mm (66.5″ × 41.5″ × 3.8″) |
| Packing Dimensions: | 1885 × 1195 × 330 mm (74.2″ × 47.0″ × 13.0″) |
| Gross Weight (with packing): | ≤ 83 kg (183.0lb) |
| Net Weight: | ≤ 64 kg (141.1 lb) |
