Description
LCD Screen
Diagonal screen size 86″
Backlight LED Backlight
Max. resolution 4K(3840 × 2160)
Brightness 350 cd/m²
Contrast 3000: 1
Response time 4 ms
Pixel pitch 0.4935 mm × 0.4935 mm
Color 10 bit
Viewing Angle Horizantal 178°, vertical 178º
Hue 92%
Active Area 1895.04 × 1065.96 mm
Touch
Touch mode IR/Optical touch
Glass Thickness 4mm
Glass transmittance ≥ 92%
Touch point 10-point touch
Input method Finger or touch pen
Touch response time ≤ 8ms
Touch precision ±2mm
Min. touch object Non-transparent object with diameter ≥ 6mm
Anti-glare Yes
Video input
4, HDMI interface
2, VGA interface
1, YPbPr interface
1, AV-IN interface
Audio input 3, AUDIO-IN interface
Audio output
EARPHONE
SPDIF-OUT
Network 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
USB interface
3, USB (PC+ Android) on front panel
2, Android-USB on side panel
1, TOUCH-USB
RS-232 interface 1
General
Casing Material Aluminum alloy
Color of Casing Black
Wall-mounting Hole (VESA) 600 × 400 mm
Wall-mounting Screw 4 × M8
Power Supply 100 to 240 VAC, 50/60Hz
Power Consumption ≤ 350 W
Standby Power Consumption ≤ 1.5 W
Working Temperature 0 to 40 º C (0 to 104 º F)
Working Humidity 20 to 80 % (non-condensing)
Specifications
Note: All specifications and appearance mentioned above are subject to the actual product.
Dimensions (without base) 2012.6 × 1226.9 × 113.9 mm
(79.2″ × 48.3″ × 4.5″)
Packing Dimensions 2235 × 1480 × 400 mm
(88.0″ × 58.3″ × 15.7″)
Gross Weight (with packing) ≤ 116.5 kg(256.8 lb)
Net Weight ≤ 89.5 kg(197.3 lb)
