Description
| General | ||
|---|---|---|
| Maximum Thrust: | 280kg(550Lbs)x2 Linear Thrust | |
| Working Voltage: | DC 12V | |
| Working Current: | 340mA x 2 | |
| Dimension of Lock Body: | 500mm × 45mm × 25mm (19.7” × 1.8” × 1.0″) | |
| Dimension of Armature Plate: | 182mm × 38mm × 12.5mm (7.2” × 1.5” × 0.5″) | |
| Suitable Doors: | Wooden Door, Glass Door, Metal Door, Fireproof Door | |
| LED Indicator: | Green (Work Status | |
| Lock Body: | Eco-friendly Zinc Electroplating Operated | |
| Shell: | Hard Anodizing Electroplating Operated | |
| Armature Plate: | Eco-friendly Zinc Electroplating Operated | |
| Working Humidity: | 0 to 95% (relative humidity) | |
| Working Temperature : | -10° C to 55° C (14° F to 131° F) | |
| Weight: | 4.2kg(9.26lb) | |
