Description
| General | |
|---|---|
| Working Current | 12 V/420 mA 24 V/210 mA |
| LED Indicator | Green (Locked),Red (Unlocked), |
| Dimension Of Lock Body (L×W×H) | 265 mm × 71.8 mm × 38.8 mm (10.43” × 2.83” × 1.53”) |
| Dimension Of Armature Plate (L×W×H) | 185 mm × 60 mm × 13 mm (7.28” × 2.36” × 0.51”) |
| Maximum Thrust | 500 kg (1200 Lbs) |
| Input Voltage | 12/24 VDC + 10% |
| Signal Output | Dry Contact Signal Output; Support Maximum Power Rate of 3A, NO Output While Locking and NC Output While Unlocking |
| Suitable Door | Wooden Door, Glass Door, Metal Door, Fireproof Door |
| Weight | 4.5 kg |
