Description
Quick Start :DS-PSG-WO-433
User Manual :DS-PSG-WO-433
Datasheet :DS-PSG-WO-433
| Features | |
|---|---|
| Tamper-Proof | Front and rear |
| Interface | |
| Indicator | Blue (on front panel), Green/Red (on PCB) |
| RF Transmission | |
| RF Frequency | 433MHz |
| RF Modulation | 2GFSK |
| RF Power | 10 dBm |
| RF Speed | 10 kbps |
| RF Range | 800 m (open area) |
| Electrical Characteristics | |
| Power Supply | 4 CR123A Batteries (default) or 12 VDC |
| Battery Life Span | 5 years in stand-by status |
| Power Consumption | Static consumption: ＜ 20 uA |
| General | |
| Operation Temperature | -25 °C to +60 °C (-13 °F to +140 °F) |
| Operation Humidity | 10% to 90% (no condensing) |
| Shell Material | PC+ABS |
| Dimension(WxHxD) | 220.5 × 205.2 × 46 mm (8.68″ × 8.08″ × 1.81″） |
| IP Rate | IP65 |
| Color | White and blue |
| Installation Method | Wall mounting |
