Description
| Camera | ||
|---|---|---|
| Image Sensor: | 1/1.8″ Progressive Scan CMOS | |
| Min. Illumination: | Color: 0.002 Lux @ (F1.2, AGC ON), 0.0027 Lux @ (F1.4, AGC ON), 0 Lux with IR B/W: 0.0002 Lux @ (F1.2, AGC ON), 0.00027 Lux @ (F1.4, AGC ON), 0 Lux with IR” |
|
| Shutter time: | 1 s – 1/100,000 s | |
| Slow shutter: | Support | |
| Lens: | 2.8 – 12 mm F1.4, horizontal angle of view 90.1° – 31° | |
| Lens Mount: | φ14 | |
| Auto Iris: | DC drive | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | 120 dB | |
| Digital noise reduction: | 3D DNR | |
| Compression Standard | ||
| Video bit rate: | 32Kbps~16Mbps | |
| Audio bit rate: | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) | |
| Image | ||
| Max. Image Resolution: | 1920 x 1080 | |
| Sub Stream: | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
|
| Third Stream: | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 × 240) |
|
| Image Enhancement: | BLC/HLC/3D DNR/Defog/EIS | |
| Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser | |
| Network | ||
| Network Storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS) | |
| Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception | |
| Protocols: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour | |
| Interface | ||
| Communication Interface: | 1 RJ45 10M / 100M Ethernet interface and 1 RS-485 interface | |
| Alarm: | With –S model: 1 input, 1 output (up to DC24V 1A or AC110V 500mA) | |
| Video Output: | 1Vp-p Composite Output (75 Ω, BNC) | |
| On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB | |
| General | ||
| Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
|
| Power Supply: | 12 V DC ± 20%, PoE (802.3at, class 4) | |
| Power Consumption: | 12 V DC ± 20%: Max. 11.25 W/0.94 A PoE (802.3at): Max. 15 W/0.31 A |
|
| Weather Proof: | IP67 | |
| IR Range: | 10 m to 30 m | |
| Dimensions: | 348.38 × 114.18 ×111.73 mm (13.72″ × 4.5″ × 4.4″) | |
| Weight: | Camera: 1900 g (4.19 lb.) With package: 2100 g (4.63 lb.) |
|
