Description
| Camera | |
|---|---|
| Image Sensor: | 2MP CMOS Image Sensor |
| Signal System: | PAL/NTSC |
| Effective Pixels: | 1920(H)*1080(V) |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s |
| Lens Mount: | M16 |
| Adjustment Range: | Pan: 0° to 360°; Tilt: 0° to 180°; Rotate: 0° to 360° |
| Day& Night: | Color |
| Video Frame Rate: | TVI: 1080p@30fps, 1080p@25fps, AHD: 1080p@30fps, 1080p@25fps. CVI: 1080p@30fps, 1080p@25fps, CVBS: PAL/NTSC |
| HD Video Output: | 1 Analog HD output |
| Synchronization: | Internal Synchronization |
| Up the Coax: | Support |
| Menu | |
| Image Mode: | STD/HIGH-SAT |
| Noise Reduction: | 3D DNR |
| Automatic Exposure: | WDR/BLC/HLC/Global |
| White Light: | AUTO/OFF |
| White Balance: | Auto/MWB |
| Private Mask: | ON/OFF, 4 programmable privacy masks |
| Motion Detection: | 4 programmable motion areas |
| AGC: | Support |
| White Balance: | Auto/Manual |
| Interface | |
| Video Out: | Switchable TVI/AHD/CVI/CVBS |
| General | |
| White Light: | Up to 20 m |
| Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | 12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera. |
| Weather Proof: | IP67 |
| Communication : | HIKVISION-C |
| Dimension: | 181.4 mm × 70 mm × 68 mm (7.14″ × 2.75″ × 2.68″) |
| Weight: | Approx. 390 g (0.86 lb.) |
