Description
Datasheet: DS-K1A802EF-B
Quick Start Guide: DS-K1A802EF-B
General
- Storage: Up to 3,000 Valid Cards;
- Operation System: Linux
- IVMS-4200: Support
- Fingerprint Capacity: Up to 3000 Fingerprints; Up to 10 Fingerprints for Each Person
- Card Reading Response Duration: < 1 s
- Fingerprint Authentication Duration: < 1 s
- Fingerprint Comparing Mode: 1:1 and 1:N, N=3000
- FAR (False Accept Rate): ≤0.001%
- FRR (False Rejection Rate): ≤0.01%
- Fingerprint Recognizer: Optical Fingerprint Recognizer Module
- Card Reading Mode: Swiping Card is Not Available
- Card Reading Distance: 0 to 5cm
- Transmission Rate: LAN: 10/100 Mbps Self-adaptive
- Wi-Fi: Support
- USB Interface: USB2.0, Type A
- LCD Screen: 2.8-inch 320 x 240 LCD-TFT Display Screen
- Key Board: Physical Keys (No Back Light)
- Audio: 1 Buzzer, 1 Loudspeaker
- Power Supply: 12 VDC/1 A
- Working Temperature: -10 ° C to 55 ° C (14 ° F to 131 ° F)
- Working Humidity: 10% to 90% (No Condensing)
- Application Situation: Indoor
- Appearance Color: Black (Included), Rose Gold (Optional), Silver (Optional), White (Optional)
- Dimension (L × W × H): 140 mm × 155 mm × 30 mm (5.51″ × 6.01″ × 1.18″)
- Installation: Surface Mounting, Metal Door Mounting, Desk Stand
