Description
Quick Start :DS-PM-WO2
User Manual:DS-PM-WO2
Datasheet :DS-PM-WO2
| Features | |
|---|---|
| Tamper-Proof | Front and rear |
| Interface | |
| Alarm Output | 2-ch, capacity: 30 VDC/1 A |
| Relay Output | 2, NO/NC |
| Switch | 1 onboard switch for turning on/off LED |
| Indicator | 3 LED: power (green), fault (orange), signal strength (green & orange) |
| RF Transmission | |
| RF Frequency | 433MHz |
| RF Speed | 10 kbps |
| RF Range | 800 m (open area) |
| Electrical Characteristics | |
| Power Supply | 9 to 15 VDC |
| General | |
| Operation Temperature | –10 °C to 55 °C (14 °F to 131 °F) |
| Operation Humidity | 10% to 90% (non-condensing) |
| Shell Material | PC + ABS |
| Dimension(WxHxD) | 160 mm × 105 mm × 28 mm (6.29″ × 4.13″ × 1.10″) |
| Weight | 165.0 g |
| Application Scenario | Indoor |
| Installation Method | Wall mounting |
