Description
Camera
- Image Sensor: 2 MP CMOS
- Signal System: PAL/NTSC
- Resolution: 1920 (H) × 1080 (V)
- Frame Rate
- TVI: 1080P@30fps, 1080P@25fps
- AHD: 1080P@30fps, 1080P@25fps
- CVI: 1080P@30fps, 1080P@25fps
- CVBS: PAL/NTSC
- Min. illumination: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter Time: PAL: 1/25 s to 1/50, 000 s
- NTSC: 1/30 s to 1/50, 000 s
- Lens: 2.8 mm, 3.6 mm, 6 mm fixed lens
- Field of View
- 2.8 mm, horizontal FOV: 106.4°, vertical FOV: 57.9°, diagonal FOV: 124.6°
- 3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7°
- 6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8°
- Lens Mount: M12
- Day & Night: ICR
- WDR (Wide Dynamic Range): Digital WDR
- Audio: Built-in mic
- Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
Menu
- Image Mode: STD/HIGH-SAT
- AGC: Yes
- Day/Night Mode: Auto/Color/BW (Black and White)
- White Balance: Auto/Manual
- AE (Auto Exposure) Mode: DWDR/BLC/HLC/Global
- Noise Reduction: 2D DNR
- Language: English
- Function: Brightness, Sharpness, Mirror, Smart IR
Interface
- Video Output: Switchable TVI/AHD/CVI/CVBS
General
- Operating Conditions: -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing)
- Power Supply: 12 VDC ± 25%
- Power Consumption Max.: 2.7 W
- Material: Plastic
- IR Range: Up to 20 m
- Communication: HIKVISION-C
- Dimensions: Φ 84.6 mm × 78.9 mm (Φ 3.33″ × 3.11″)
- Weight: Approx. 140.5 g (0.31 lb.)
